Model Year | 2025 |
---|---|
Top Tube | 20 |
Rear Triangle | 13.25" |
Head Tube | 74.5 |
Stand Over | 8.5" |
BB Height | 11.6" |
Frame | Curb |
Material | Steel |
Fork | Kink Lance Fork 100% Hi-Ten Steel Tapered Fork Legs |
Fork Offset | 32mm |
Compression Bolt Size | Star Nut |
Handlebars | Kink T875 Bar 8.75" 100% Hi-Ten Steel |
Bar Style | 2 Piece |
Bar Rise | 8.75" |
Grips | Kink Ace Grips |
Grip Style | Flangeless |
Bar Ends | Kink Thrust |
Bar End Size | 31 |
Stem | Mission Control TL 50mm |
Stem Style | Top Load |
Stem Rise | 32mm |
Stem Reach | 50mm |
Headset | Standard 1 1/8"" Threadless Headset |
Brake Lever | Mission Token |
Lever Orientation | Right |
Cable Type | Linear |
Brakes | Mission Cease V2 |
Frame Brake Style | Welded |
Cranks | Mission Triumph 3pc Tubular Chromoly 170mm - 8 Spline |
Crank Style | 3pc |
Crank Length | 170mm |
Drive Side Option | RHD |
Spindle Size | 19mm |
Spindle Splines | 8 |
Bottom Bracket | Unsealed American |
Bottom Bracket Style | American |
Pedals | Kink Hemlock Pedals |
Pedal Size | 9/16" |
Chain | Mission 410 |
Chain Style | 410 |
Sprocket | Mission Breach 25T |
Sprocket Size | 25t |
Hubs | Mission Reserve Unsealed 3/8" Axle / Mission Function Semi-Sealed Cassette 14mm |
Driver | 9 Tooth |
Spoke Holes | 36 |
Spoke Style | J Bend |
Rims | Mission X7 / Mission X7 |
Rim Wall | Single Wall |
Wheel Size | 20 |
Seat | Mission Warsaw Combo |
Seat Style | Combo |
Seat Size | Fat |
Seat Post | Mission Combo Steel Post |
Post Diameter | 25.4mm |
Tires | Mission Tracker 2.4 |
Bead Type | Wire |
Tire Size | 20x2.4 |
PSI Rating | 60 |
Valve Type | Schrader |
Pegs | None |
